產品特點
- High-Performance Cooling: The NZXT Turbine pump is engineered for high flow and head pressure, delivering efficient, low-noise cooling to keep your CPU performing at its best under heavy workloads.
- Custom LCD Screen: Display real-time system temps, animated GIFs, custom images, or web integrations like Spotify and YouTube on a bright 1.54" square LCD — fully customizable through NZXT CAM software.
- Seamless RGB: The RGB Core single-frame fan delivers strong airflow and vibrant, customizable lighting—plus an easy install with just four screws and a single cable.
- Easy Installation: Pre-applied thermal paste and a single breakout cable from the pump cap speed up installation and reduce cable clutter.
- Wide Compatibility: Includes tool-free mounting brackets that support the latest AMD® and Intel® CPU sockets, including AM5 and LGA 1851.
- Durable and Reliable: Reinforced rubber tubing with nylon-braided sleeving ensures long-term durability and easy routing during installation.
- Optimized Cold Plate: The split-flow copper cold plate channels coolant to the CPU’s hottest areas for better heat transfer, lower temps, and more consistent thermal performance.
- NZXT CAM Software: Use NZXT CAM to monitor temps, customize the LCD display, and control fan and pump speeds — all through an intuitive, easy-to-use interface.
產品規格
DISPLAY
Panel Type: Transmissive TFT, 262K color
Diagonal: 1.54 in / 39.1 mm
Resolution: 240 x 240 px
Refresh Rate: 30 Hz
Brightness: 300 cd/m²
Colors: 18-bit
Orientation: Software adjustable
PUMP
Name: NZXT Turbine
Motor Speed: 1,200 – 2,800 ± 300 RPM
Power: 12 V DC, 0.3 A
CAP
Diameter: 2.87 in / 72.95 mm
Height: 2.2 in / 55.97 mm
Housing Material: Plastic
COLD PLATE
Dimensions: 56 mm x 56 mm
Type: Split flow
Material: Copper
RADIATOR
Dimensions (L x W x H): 401 x 120 x 27 mm
Material: Aluminum
TUBING
Length: 420 mm
Material: CIIR rubber with Nylon braided sleeve
FAN SPECS
Model: F360 RGB Core (EV) Fan
Color: White
Dimensions: 360 x 120 x 26 mm
Quantity: 1
Speed: 500 - 2,400 ± 250 RPM per fan
Airflow: 75.05 CFM per fan
Static Pressure: 3.07 mm-H₂O per fan
Noise Level: 31.9 dBA per fan
Power Consumption: 12V DC, 0.79 A, 9.48 W | 5V DC, 0.81 A, 4.05 W
Connector: 8-pin for PWM & RGB
Bearing: Fluid Dynamic Bearing
Lifespan: 60,000 hours
LED Quantity: 8 LEDs per fan
Cable Length: 600 mm
Materials: Plastic, rubber, PCB
SOCKET SUPPORT
Intel®: LGA 1851/1700, 1200/115X
AMD®: AM5, AM4
CPU SUPPORT
Intel®: Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD®: AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3
PRODUCT INFO
Warranty: 6 Years
Model Number: RL-KR360-W2
UPC: 810074845359
EAN: 5056547205267
