Specifications | |
---|---|
Model | CS-H4-R201-1H3EKFL |
Camera | |
Image Sensor | 1/2.8" Progressive Scan CMOS |
Shutter Speed | Self-adaptive shutter |
Lens |
2.8 mm @ F1.6 Viewing angle: 106° (Horizontal), 122° (Diagonal) 4 mm @ F1.6 Viewing angle: 86° (Horizontal), 102° (Diagonal) |
Lens Mount | M12 |
Day / Night Switch | IR-Cut filter with auto-switching |
DNR | 3D DNR |
WDR | WDR |
BLC | Supports |
IR Night Vision Distance | Up to 30 m / 98 ft. |
Video & Audio | |
Max. Resolution | 2K (2304 × 1296) |
Frame Rate | Self-Adaptive during network transmission |
Video Compression | H.265 / H.264 |
Video Bit Rate | Ultra-HD; HD; Standard Adaptive bit rate. |
Audio Bit Rate | Self-adaptive |
Network | |
Protocol | EZVIZ Cloud Proprietary |
Interface Protocol | EZVIZ Cloud Proprietary Protocol |
Wired Network | RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
Functions | |
Smart Alarm |
Motion detection AI-powered human shape detection AI-Powered vehicle shape detection |
Customized Alert Area | Supports |
Two-way Talk | Supports |
General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
Storage | |
Local Storage | Supports microSD card (Up to 512 GB) |
Cloud Storage | Supports EZVIZ CloudPlay storage (Subscription required) |
General | |
IP Grade | IP67 |
Operating Conditions |
-30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing) |
Power Supply | DC 12V/1A, Support PoE power supply |
Power Consumption | Max. 8 W |
Dimensions |
Product dimension: 106 × 106 × 90 mm (4.17 × 4.17 × 3.54 inch) Package dimension: 133 × 131 × 159 mm (5.24 × 5.16 × 6.26 inch) |
Weight |
Net weight: 240 g (8.47 oz) Weight with package: 400 g (14.11 oz) |
In the box | |
In the box | - H4 PoE Camera |
- Drill Template | |
- Screw Kit | |
- Regulatory Information × 2 | |
- Quick Start Guide | |
Certifications | |
Certifications | CE / WEEE / RoHS / REACH |
