Model
T500MV
Color
Solar Eclipse Gray
Operating System
Windows 11 Home - ASUS recommends Windows 11 Pro for business
Windows 11 Pro - ASUS recommends Windows 11 Pro for business
Processor
Intel® Core™ i7-13620H Processor 2.4 GHz (24MB Cache, up to 4.9 GHz, 10 cores, 16 Threads)
Intel® Core™ i5-13420H Processor 2.1 GHz (12MB Cache, up to 4.6 GHz, 8 cores, 12 Threads)
Graphics
NVIDIA® GeForce RTX™ 3050 6GB GDDR6 : 1x DP, 1x HDMI, 1x DVI-D
NVIDIA® GeForce RTX™ 5060TI DUAL 8GB GDDR7 : 3xDP, 1x HDMI
NVIDIA® GeForce RTX™ 5060TI DUAL 16GB GDDR7 : 3xDP, 1x HDMI
NVIDIA® GeForce RTX™ 5060 DUAL 8GB GDDR7 : 3xDP, 1x HDMI
NVIDIA® GeForce RTX™4060 DUAL 8GB GDDR6:3xDP, 1x HDMI (up to 242 AI TOPs)
Memory
2x DDR5 SO-DIMM slot
16GB DDR5 SO-DIMM
Memory max up to:64GB
16GB DDR5 SO-DIMM x 2
8GB DDR5 SO-DIMM
SATA
2 x SATA 6.0Gb/s ports
Storage
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD
1TB M.2 2280 NVMe™ PCIe® 4.0 SSD
Front I/O Ports
1x 3.5mm combo audio jack
2x USB 3.2 Gen 1 Type-A
1x USB 3.2 Gen 1 Type-C
Rear I/O Ports
1x RJ45 Gigabit Ethernet
1x HDMI 1.4
1x Displayport 1.4
1x 7.1 channel audio (microphone, line-out, Line-in)
1x Kensington lock
4x USB 2.0 Type-A
Expansion Slots(includes used)
1x PCIe® 4.0 x 16 (operating at PCIe® 4.0 x8)
1x M.2 connector for WiFi
2x M.2 2280 connector for storage
2x DDR5 SO-DIMM slot
Audio
High Definition 7.1 Channel Audio
Network and Communication
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card
Power Supply
330W power supply (80+ Platinum, peak 660W)
500W power supply (80+ Platinum, peak 1000W)
Weight
5.90 kg (13.01 lbs)
Dimensions (W x D x H)
15.55 x 29.64 x 34.70 cm (6.12" x 11.67" x 13.66")
Not including chassis feet and GPU bracket.
Ecolabels & Compliances
RoHS
REACH
Security
HDD User Password Protection and Security
Kensington Security Slot™(7x 3mm)
Discrete Trusted Platform Module (TPM) 2.0
Included in the Box (Optional)
Gaming RGB Mouse(USB)
Gaming RGB Keyboard(USB)
Gaming mouse (USB)
Gaming keyboard (USB)
Thermal
Air Cooler
