Access performance engineering with ample ventilation and an air guide which directs airflow towards components to improve GPU cooling.
Elevate your space with an aerodynamic design aesthetic featuring a sleek, rockface-inspired mesh front panel.
Create a powerful gaming system with space for graphics cards up to 349 mm in length and E-ATX (277 mm) motherboard compatibility.
Ambience Pro RGB Version
Create the right atmosphere with advanced ARGB Gen 2 ambient lighting, including an animated PC startup effect.
Ambience Pro RGB Version
Customize your lighting and fans easily with a download-free configuration tool, accessed via the included Adjust Pro Hub.
Enjoy a smooth build experience with easily removable panels, including a sliding top panel featuring a fabric tab.
Includes three high-performance Momentum 14 fans, featuring LCP blades and true FDB bearings for improved cooling and quieter operation.
Cool your build further with up to a 280 mm top radiator and 360 mm front radiator, with removable brackets for easy installation.
Connect your devices easily with a top I/O featuring a 20 Gbps USB Type-C port, two USB-A ports and a combined audio jack.
Achieve a neat and tidy look with a clean interior layout featuring a cable cover and new cable aligners for easy routing.
Experience advanced cooling and expressive, aerodynamic design in a spacious format. An evolution of our mesh performance series, Meshify 3 XL offers performance-boosting engineering upgrades, three powerful Momentum fans, and next-level atmospheric lighting in Ambience Pro RGB versions.
3.5"/2.5" drive mounts
2/4
Dedicated 2.5" drive mounts
1
5.25” drive mounts
-
Expansion slots
7
Adjust Pro Hub
Included in Ambience Pro RGB version
Ambience Case Lighting
Ambience Pro RGB version
Front interface
1 x USB Type-C 20 Gbps, 2 x USB Type-A 5 Gbps, 1x Audio Combo Jack, Power button
Total fan mounts
10 (120 or 140 mm)
Front fan
3x 120/140 mm, 2x 180 mm (3 x 140 mm Momentum Included)
Top fan
3x 120/140 mm
Rear fan
1x 120/140 mm
Bottom fan
-
Side fan
3x 140 mm (no 120 support without radiator)
Dust filters
PSU (Bottom)
Cable routing space
37,5 mm
Cable cover
Yes
Cable organizers
3 Hook-and-loop straps + 3 Cable Aligners
Tool-less push-to-lock
Both Side Panels, Bottom Filter, Front Panel, Top Panel
Captive thumbscrews
Top Radiator Bracket, Air Guide, PSU Bracket
Left side panel
Industrial steel (Solid), Tempered Glass (TG/RGB/Ambience Pro RGB)
Right side panel
Industrial steel
Power supply type
ATX
Motherboard compatibility
E-ATX (330 mm) / ATX / mATX / ITX / EE-ATX / SSI-EEB / SSI-CEB
PSU max length
230 mm
GPU max length
512mm
GPU max height
189 mm (7 slot) including cables
CPU cooler max height
182 mm
Front radiator
280/360 mm
Top radiator
360/420 (up to 475) mm
Rear radiator
Up to 120/140 mm
Bottom radiator
-
Case dimensions (LxWxH)
575 x 245 x 515 mm
Case dimensions w/o feet/protrusions/screws
565 x 245x 515
Package dimensions
596 x 350 x 550 mm
Net weight
10.5 kg (Solid) 10.9 kg (TG and RGB) 11.4 kg (Ambience Pro RGB)
Gross weight
12.4 kg (Solid) 13 kg (TG and RGB) 13.3 kg (Ambience Pro RGB)
Package contents
Case, Accessory Box, Manual, Red Note
Accessory Box content (Solid/TG/RGB)
PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8
Accessory Box content (Ambience Pro RGB)
PSU Screws x4, MB Screws x12, SSD screws M3 x20, Zip tie x5, HDD rubber x8, MB standoff x4, HDD screws x8, 500 mm Fractal Connect Cable x1, Legacy Splitter Cable
EAN
Black Solid: 7340172707219 Black TG Light Tint: 7340172707226 Ambience Pro RGB Black TG Light Tint: 7340172707233 Black RGB TG Light Tint: 7340172709527 Ambience Pro RGB White TG Clear Tint: 7340172707240 White RGB TG Clear Tint: 7340172709534
UPC
Black Solid: 843276107215 Black TG Light Tint: 843276107222 Ambience Pro RGB Black TG Light Tint: 843276107239 Black RGB TG Light Tint: 843276109523 Ambience Pro RGB White TG Clear Tint: 843276107246 White RGB TG Clear Tint: 843276109530
Product Code
Black Solid: FD-C-MES3X-01 Black TG Light Tint: FD-C-MES3X-02 Ambience Pro RGB Black TG Light Tint: FD-C-MES3X-03 Black RGB TG Light Tint: FD-C-MES3X-04 Ambience Pro RGB White TG Clear Tint: FD-C-MES3X-05 White RGB TG Clear Tint: FD-C-MES3X-06
Warranty
2 Years
